Manufacturer: Brocade Communications Systems, Inc
Manufacturer Part Number: 100G-CFP2-LR4-10KM
Manufacturer Website Address: http://www.brocade.com
Brand Name: Brocade
Product Name: 100 Gbps LR4 (10 KM) CFP2 Optical Transceiver
Marketing Information: Optimized, Certified Optical Transceivers for Extending Service Provider and Data Center Networks
Today’s service provider networking environments and enterprise data centers are undergoing an infrastructure transformation, requiring higher speeds, greater scalability, and higher levels of performance and reliability to better meet the demands of business. As speed and performance needs increase, optical transceivers have become an integral part of overall system design. However, optical transceiver design margins and parameters vary widely, and can be the difference between an optimized, highly reliable fabric, and incompatibility issues that drive up support costs.
The Brocade® 100 Gbps LR4 (10 km) CFP2 Ethernet Optical Transceiver, part of the Brocade family of optical transceivers, is optimized to fully leverage the Brocade MLXe® Series and Brocade VDX® Switches with 100 Gbps capabilities. Together, these optical transceivers provide state-of-the-art performance and help IT organizations achieve new levels of infrastructure consolidation while expanding the capabilities of their applications and services.
END-TO-END COMPATIBILITY AND RELIABILITY
Brocade 100 Gbps LR4 CFP2 Ethernet Optical Transceivers support highly reliable operations in service provider and data center networks, and are optimized for Brocade switching platforms. They undergorigorous qualification and certification testing to provide an end-to-end solution that is easier to maintain-helping improve the availability of data center networks
KEY FEATURES
Brocade 100 Gbps LR4 C Form-Factor Pluggables 2 (CFP2) are hot-swappable, low-voltage (3.3 V) digital diagnostic Ethernet optical transceivers that support high-speed serial links over single-mode optical fiber at signaling rates up to 100 Gbps. They comply with the CFP2 MSA and optical (IEEE 802.3ba) specifications. supporting mission-critical applications.
Product Type: CFP2
Packaged Quantity: 1
Technical Information
Application/Usage:
- Data Networking
- Optical Network
Interfaces/Ports
Total Number of Ports: 1
Connector Type: LC
Interfaces/Ports Details: 1 x LC Duplex 100GBase-LR4 Network
Media & Performance
Media Type Supported: Optical Fiber
Fiber Optic Cable Standard: 9 µm
Fiber Mode Supported: Single-mode
Ethernet Technology: 100 Gigabit Ethernet
Network Technology: 100GBase-LR4
Physical Characteristics
Form Factor: Hot-pluggable
Height: 0.7″
Width: 1.6″
Depth: 4.2″
Miscellaneous
Compatibility: MSA Compliant
Environmentally Friendly: Yes
Environmental Certification: RoHS
