Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: CSS11501
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Series: 11500
Product Model: 11501
Product Name: 11501 Content Switch
Marketing Information:
The Cisco CSS 11500 Content Services Switch enables businesses to simultaneously reduce costs by optimizing data center resources and boosting productivity, as well as offering a superior online experience for customers, business partners, and employees. Through content fast switching and forwarding, the Cisco CSS 11500 switch improve utilization, responsiveness, availability, scalability, and security of Web sites, server farms, cache clusters, and firewall systems.
Product Type: Layer 3 Switch
Interfaces/Ports
Total Number of Network Ports: 8
Port/Expansion Slot Details:
- 8 x Fast Ethernet Network
- 1 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported: Twisted Pair
Ethernet Technology: Fast Ethernet
Network Technology: 10/100Base-TX
I/O Expansions
Number of Total Expansion Slots: 1
Expansion Slot Type: GBIC
Network & Communication
Layer Supported: 7
Management & Protocols
Manageable: Yes
Power Description
Power Source: Power Supply
Power Consumption: 150 W
Physical Characteristics
Height: 1.7″
Width: 17.3″
Depth: 18.1″
Weight (Approximate): 18 lb
Miscellaneous
Package Contents:
- Content Services Switch
- Anti-static wrist strap
- Four rubber feet
- Mounting brackets and hardware
- RJ-45 to female 25-pin sub-d connector
- RJ-45 to female 9-pin sub-d connector
- RJ-45 console cable
- Cisco 11500 Series Content Services Switch Hardware Installation Guide
- Standard software license key. If you ordered the Enhanced feature set or the Secure Management option (which include the Secure Shell Host option and SSL strong encryption for the Device Management software), additional Claim Certificates will be included in the accessory kit.
- WebNS V7.1X Standard Feature Set for CSS11501
- Power Cord,110V
- CSS11500 PCMCIA Hard Disk
- CSS11500 Upgrade: 144MB to 288MB RDRAM
Warranty
Limited Warranty: 1 Year
Additional Warranty Information: Replacement, Repair or Refund Procedure for Hardware:
- Cisco or its service center will use commercially reasonable efforts to ship a replacement part within ten (10) working days after receipt of the RMA request. Actual delivery times may vary depending on Customer location.
