Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: AIR-AP1242AG-A-K9
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Line: Aironet
Product Series: 1240AG
Product Name: Aironet 1242AG Access Point
Marketing Information:
Cisco Aironet 1232AG 802.11a/b/g Wireless Access Point delivers the versatility, high capacity, security, and enterprise-class features demanded by WLAN customers. It is designed specifically for challenging RF environments like factories, warehouses, and large retail establishments that require the antenna versatility associated with connectorized antennas, a rugged metal enclosure, and a broad operating temperature range. It extends the security, scalability, reliability, ease of deployment, and manageability available in wired networks to the wireless infrastructure.
Running Cisco IOS Software, makes the Access Point supports link role flexibility which provides both access point and bridge functionality through configuration of each radio as an access point, repeater, root bridge, non-root bridge, or workgroup bridge. This configuration flexibility enables the Access Point to address applications ranging from basic wireless LAN coverage to wireless LAN coverage with wireless backhaul to more traditional bridging applications. The access point without wired connection will use the 5-GHz radio to wirelessly connect to the other access point for backhaul to the network.
Product Type: Wireless Access Point
Technical Information
Wireless LAN Standard: IEEE 802.11a/b/g
Frequency Band:
- 2.41 GHz
- 5.15 GHz
Total Number of Antennas: 2
Indoor Antenna Range: 460 ft
Outdoor Antenna Range: 950 ft
Wireless Transmission Speed: 54 Mbit/s
Data Encryption: Yes
Encryption Standard:
- WEP
- AES
- WPA2
- WPA
Interfaces/Ports
Ethernet Technology: Fast Ethernet
Management Port: Yes
Physical Characteristics
Form Factor:
- Desktop
- Ceiling Mountable
Height: 1.1″
Depth: 8.5″
Weight (Approximate): 2 lb
Miscellaneous
Package Contents:
- Aironet 1242AG 802.11a/b/g Wireless Access Point
- Cisco Aironet 1240AG Series Power Module (universal power module)-optional
- Quick Start Guide: Cisco Aironet 1240AG Series Access Point
- Safety Warnings for Cisco Aironet 1240AG Series Access Points
- Cisco product registration and Cisco documentation feedback cards
Mounting hardware kit:
- One mounting plate with cable security bracket
- Two suspended ceiling T-rail clips, spacers (accommodates standard and recessed T-rails), and nuts
- One security hasp
- Two 6 x 32 x 1/2 in. pan head Phillips machine screws
- Four 8 x 18 x 3/4 in. pan head Phillips sheet metal screws
- Four #8 plastic wall anchors
- One 10 x 24 nut (for ground stud on mounting bracket)
- Four rubber foot pads
- Two cable tie wraps
Warranty
Limited Warranty: 1 Year
