Cisco Catalyst 2916M-XL Ethernet Switch

The Catalyst 2916M-XL Ethernet Switch that supply auto-sensing 10BaseT or 100BaseT connections on all ports. The switch also referred to as Catalyst 2900 switches-can be deployed as backbone switches aggregating 100BaseT traffic from other switches and hubs or in mixed configurations connecting hubs, switches, servers, and desktops.

Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 16
Port/Expansion Slot Details: 16 x Fast Ethernet Network
Media & Performance
Ethernet Technology: Fast Ethernet
Network Technology: 10/100Base-TX
I/O Expansions
Number of Total Expansion Slots: 2
Network & Communication
Layer Supported: 2
Management & Protocols
Manageable: Yes
Power Description
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Form Factor:

• Rack-mountable
• Wall Mountable
• Desktop

Height: 3.5″
Width: 17.5″
Depth: 12″
Weight (Approximate): 15.43 lb
Miscellaneous
Package Contents:

• Catalyst 2916M-XL Ethernet Switch
• Catalyst 2900 Series XL Installation and Configuration Guide
• Quick Start: Catalyst 2900 Series XL Series Cabling and Setup
• Cisco Documentation CD-ROM package
• Cisco Information Packet, containing warranty, safety, and support information
• AC power cord
• 4 x Rubber feet for mounting the switch on a table
• 2 x Mounting brackets
• 1 x cable guide for attaching the cable guide to one of the mounting brackets
• 2 x black Phillips machine screw for attaching the cable guide to one of the mounting brackets
• 4 x Phillips flat-head screws for attaching the brackets to the switch
• 4 x Phillips truss-head screws for attaching the brackets to the switch
• 4 x Phillips machine screws for attaching the brackets to a rack
• 1 x RJ-45-to-RJ-45 rollover cable
• 1 x RJ-45-to-DB-9 adapter
• 1 x RJ-45-to-DB-25 male adapter
• 1 x RJ-45-to-DB-25 female adapter

Warranty
Limited Warranty: 90 Day
