Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: ESW-540-8P-K9
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Series: ESW 500
Product Model: ESW-540-8P
Product Name: ESW-540-8P Ethernet Switch with PoE
Marketing Information:
The Cisco ESW-540-8P is a cost-effective 8-port 10/100/100 PoE switch with one expansion port that easily integrates with other Cisco Small Business Pro Series products and the Cisco Smart Business Communications System. It provides a high-performance switching founation to support a data, voice, video, and wireless networking solution for small businesses. The switch is simple to configure with either the embedded GUI configuration utility or Cisco Configuration Assistant. It provides eight Gigabit Ethernet ports of standard Power over Ethernet that can connect and power wireless access points, IP telephones, IP-based video surveillance cameras, and other network endpoints. The Cisco ESW 540-8P includes a 5-year enhanced warranty with next-business-day product replacement (where available).
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 9
Port/Expansion Slot Details:
- 8 x Gigabit Ethernet Network
- 1 x Gigabit Ethernet Expansion Slot
Media & Performance
Ethernet Technology: Gigabit Ethernet
Network Technology: 10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots: 1
Expansion Slot Type: SFP
Shared SFP Slot: Yes
Number of SFP Slots: 1
Network & Communication
Layer Supported: 2
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: Yes
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Form Factor: Rack-mountable
Height: 1.7″
Width: 17.3″
Depth: 0.6″
Weight (Approximate): 2.25 lb
Miscellaneous
Package Contents:
- ESW-540-8P Ethernet Switch with PoE
- Power cord
- Mounting hardware
- Serial cable
- CD-ROM with user documentation (PDF)
- Quick-start guide
Warranty
Limited Warranty: 5 Year
