Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: IE-4000-4GS8GP4G-E
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Series: 4000
Product Model: IE-4000-4GS8GP4G-E
Product Name: IE-4000-4GS8GP4G-E Layer 3 Switch
Marketing Information: The Cisco® Industrial Ethernet (IE) 4000 Series is the latest addition to our ruggedized switching platforms and provides superior high-bandwidth switching and proven Cisco IOS® Software-based routing capabilities for industrial environments. The IE 4000 Series delivers highly secure access and industry-leading convergence using the Cisco Resilient Ethernet Protocol (REP) and is built to withstand extreme environments while adhering to overall IT network design, compliance, and performance requirements.
The IE 4000 Series is ideal for industrial Ethernet applications where hardened products are required, including factory automation, energy and process control, intelligent transportation systems (ITS), oil and gas field sites, city surveillance programs, and mining. With improved overall performance, greater bandwidth, a richer feature set, and enhanced hardware, the Cisco IE 4000 Series complements the current industrial Ethernet portfolio of related Cisco industrial switches, such as the Cisco IE 2000 and IE 3000.
The Cisco IE 4000 can easily be installed in your network. Through a user-friendly web device manager, the Cisco IE 4000 provides easy out-of-the-box configuration and simplified operational manageability to deliver advanced security, data, video, and voice services over industrial networks.
Product Type: Layer 3 Switch
Interfaces/Ports
Total Number of Network Ports: 12
Uplink Port: Yes
Modular: No
Stack Port: No
Port/Expansion Slot Details:
- 8 x Gigabit Ethernet Network
- 4 x Gigabit Ethernet Uplink
- 4 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
- Twisted Pair
- Optical Fiber
Ethernet Technology: Gigabit Ethernet
Network Technology:
- 1000Base-T
- 1000Base-X
I/O Expansions
Number of Total Expansion Slots: 4
Expansion Slot Type: SFP
Shared SFP Slot: Yes
Number of SFP Slots: 4
Network & Communication
Layer Supported: 3
Management & Protocols
Manageable: Yes
Power Description
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Form Factor: Rail-mountable
Height: 5.1″
Width: 6.1″
Depth: 6.1″
Weight (Approximate): 6.35 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification:
- RoHS
- China RoHS
TAA Compliant: Yes
Warranty
Limited Warranty: Lifetime
