Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: RC460-PL001
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Model: 9260-8i
Product Name: LSI MegaRAID 9260-8i 8-port SAS RAID Controller
Marketing Information:
The eight-port MegaRAID SAS 9260-8i provides a new level or performance and data protection for internal storage systems using up to 32 SATA or SAS hard drives or solid state drives. With data transfer rates of up to 6Gb/s per port, the MegaRAID SAS 9260-8i brings users new features and improved performance while continuing to support all the features of the previous 3Gb/s SATA and SAS generation. This value line controller, ideal for inside-the-box connectivity, employs the latest in RAID-on-Chip technology and complies with the PCI Express 2.0 specification for high-bandwidth applications.
Product Type: SAS Controller
Technical Information
Host Interface: PCI Express 2.0 x8
Controller Type: Serial ATA/300
RAID Supported: Yes
RAID Levels:
- 0
- 1
- 5
- 6
- 10
- 50
- 60
Maximum Data Transfer Rate: 600
Interfaces/Ports
Total Number of SAS Ports: 2
Number of SAS Ports (Internal): 2
SAS Connector Details: 2 x SFF-8087
Physical Characteristics
Form Factor: Plug-in Card
Card Height: Low-profile
Height: 2.5″
Width: 6.6″
Miscellaneous
Platform Supported:
- PC
- SPARC
