Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: N9K-C92348GC-X
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Line: Nexus
Product Series: 9200
Product Model: 92348GC-X
Product Name: Nexus 92348GC-X Ethernet Switch
Marketing Information:
The Cisco Nexus 92348GC-X Switch is a 1RU switch based on Cisco Cloud Scale technology and supports 0.696 Tbps of bandwidth and over 250 mpps. The 48 1GBASE-T downlink ports on the 9248GC-X can be configured to work as 100-Mbps, 1-Gbps ports. The 4 ports of SFP28 can be configured as 1/10/25-Gbps and the 2 ports of QSFP28 can be configured as 40- and 100-Gbps ports. The Cisco Nexus 92348GC-X is ideal for big data customers that require a Gigabit Ethernet ToR switch with local switching and for management switch use cases.
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 48
Uplink Port: Yes
Modular: Yes
Port/Expansion Slot Details:
- 48 x Gigabit Ethernet Network
- 4 x 25 Gigabit Ethernet Expansion Slot
- 2 x 100 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
- Twisted Pair
- Optical Fiber
Ethernet Technology:
- Gigabit Ethernet
- 25 Gigabit Ethernet
- 100 Gigabit Ethernet
Network Technology:
- 10/100/1000Base-T
- 25GBase-X
- 100GBase-X
I/O Expansions
Number of Total Expansion Slots: 6
Expansion Slot Type:
- SFP28
- QSFP28
Network & Communication
Layer Supported: 3
Management & Protocols
Manageable: Yes
Power Description
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Height: 1.7″
Width: 17.3″
Depth: 18.5″
Weight (Approximate): 14.12 lb
