Cisco QSFP-100G-SM-SR QSFP Module

General Information
Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: QSFP-100G-SM-SR=
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Model: QSFP-100G-SM-SR
Product Name: QSFP-100G-SM-SR QSFP Module
Marketing Information: The Cisco QSFP-100G-SM-SR QSFP module supports link lengths of up to 2 kilometers over a standard pair of G.652 Single-Mode Fiber (SMF) with duplex LC connectors. The 100 Gigabit Ethernet signal is carried over four wavelengths. Multiplexing and demultiplexing of the four wavelengths are managed within the device. The operating temperature range is from +10 to +60°C with an optical link budget of 4.2 decibels. This 4.2-decibel link budget offers the ability to support the loss from patch panels in the link in a data center environment. QSFP-100G-SM-SR is interoperable with QSFP-100G-CWDM4-S.
Product Type: QSFP
Technical Information
Application/Usage:

• Data Networking
• Optical Network

Interfaces/Ports
Total Number of Ports: 1
Connector Type: LC
Interfaces/Ports Details: 1 x LC Duplex 100GBase-CWDM4 Network
Media & Performance
Media Type Supported: Optical Fiber
Fiber Mode Supported: Single-mode
Ethernet Technology: 100 Gigabit Ethernet
Network Technology: 100GBase-CWDM4
Physical Characteristics
Form Factor: Hot-swappable
Height: 0.5″
Width: 0.7″
Depth: 2.9″
Weight (Approximate): 0.22 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
Warranty
Limited Warranty: 1 Year
