Overview
General Information
Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: ONS-SC-2G-55.7
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Name: SFP (mini-GBIC) Module
Marketing Information: The Cisco ONS 2.5-Gbps fixed-rate OC-48/STM-16 DWDM optics provide both transmit and receive optical interfaces in a single SFP footprint pluggable into any of the four ASAP 4-PIO slots. Each port interface operates at the standard SONET/SDH (Telcordia GR-253-CORE, ITU G.703 and ITU-T G.694.1) 2488.32-Mbps bit rate. The Cisco ONS 2.5-Gbps fixed-rate OC-48/STM-16 DWDM SFP uses a duplex LC connector on the SFP faceplate that is routed through a fiber tray on to the cable-routing module for termination. The Cisco ONS 2.5-Gbps fixed-rate DWDM SFP carries both concatenated payloads of STS-3c/VC-4, STS-6c/VC-4-2c, STS-9c/VC-4-3c, STS-12c/VC-4-4c, STS-24c/VC-4-8c, and STS-48c/VC-4-16c and nonconcatenated payloads on an STS-1 basis. In SONET mode, each optical port can be provisioned as STM-16 to enable the tunneling of SDH payloads in the form of STS-Nc concatenated payload over a SONET network. This helps enable North American service providers to transport SDH traffic from international cable landing points to customer sites. When operated within the outlined specifications (refer to Table 5), each port interface transports a 2.5-Gbps signal with a minimum BER of 10E-12. The Cisco ONS 2.5-Gbps fixed-rate OC-48/STM-16 DWDM SFP provides 32 wavelengths in the ITU-T G.694.1 C-Band channel plan.
Product Type: SFP (mini-GBIC)
Technical Information
Application/Usage:
Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: ONS-SC-2G-55.7
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Name: SFP (mini-GBIC) Module
Marketing Information: The Cisco ONS 2.5-Gbps fixed-rate OC-48/STM-16 DWDM optics provide both transmit and receive optical interfaces in a single SFP footprint pluggable into any of the four ASAP 4-PIO slots. Each port interface operates at the standard SONET/SDH (Telcordia GR-253-CORE, ITU G.703 and ITU-T G.694.1) 2488.32-Mbps bit rate. The Cisco ONS 2.5-Gbps fixed-rate OC-48/STM-16 DWDM SFP uses a duplex LC connector on the SFP faceplate that is routed through a fiber tray on to the cable-routing module for termination. The Cisco ONS 2.5-Gbps fixed-rate DWDM SFP carries both concatenated payloads of STS-3c/VC-4, STS-6c/VC-4-2c, STS-9c/VC-4-3c, STS-12c/VC-4-4c, STS-24c/VC-4-8c, and STS-48c/VC-4-16c and nonconcatenated payloads on an STS-1 basis. In SONET mode, each optical port can be provisioned as STM-16 to enable the tunneling of SDH payloads in the form of STS-Nc concatenated payload over a SONET network. This helps enable North American service providers to transport SDH traffic from international cable landing points to customer sites. When operated within the outlined specifications (refer to Table 5), each port interface transports a 2.5-Gbps signal with a minimum BER of 10E-12. The Cisco ONS 2.5-Gbps fixed-rate OC-48/STM-16 DWDM SFP provides 32 wavelengths in the ITU-T G.694.1 C-Band channel plan.
Product Type: SFP (mini-GBIC)
Technical Information
Application/Usage:
- Optical Network
- Data Networking
Interfaces/Ports
Total Number of Ports: 1
Connector Type: LC
Interfaces/Ports Details: 1 x LC Duplex OC-48/STM-16 Network
Media & Performance
Media Type Supported: Optical Fiber
Fiber Mode Supported: Single-mode
Ethernet Technology: Gigabit Ethernet
Network Technology: OC-48/STM-16
Physical Characteristics
Height: 0.5″
Width: 0.3″
Depth: 2.2″
Weight (Approximate): 0.06 lb
Miscellaneous
Compatibility: Cisco ONS 15600 Series Any Service Any Port Optical Cards
Warranty
Limited Warranty: 5 Year
