Manufacturer: Cisco Systems, Inc
Manufacturer Part Number: WS-X6716-10T-3C
Manufacturer Website Address: http://www.cisco.com
Brand Name: Cisco
Product Model: WS-X6716-10T-3C
Product Name: WS-X6716-10T-3C Switching Module
Marketing Information:
The 16-port 10 Gigabit Ethernet copper module provides up to 130 10 Gigabit Ethernet copper ports in a single Cisco Catalyst 6509 Switch chassis and 260 10 Gigabit Ethernet ports in a Cisco Catalyst 6500 Virtual Switching System (VSS) 1440 and is primarily designed for data center access with a secondary use case for switch-to-switch connectivity. It consists of 4 port groups of 4 ports each. Users can operate each port group in either over subscription mode (2 to 4 ports used per port group) or performance mode (1 port used per port group), providing the flexibility to use some ports for connection to servers and other ports for interconnection of switches. In performance mode, up to 4 10 Gigabit Ethernet ports can be used to create a virtual switch link in a VSS.
Product Type: Switching Module
Technical Information
Application/Usage:
- Data Networking
- Switching Network
Interfaces/Ports
Total Number of Ports: 16
Connector Type: RJ-45
Interfaces/Ports Details: 16 x RJ-45 10GBase-T LAN
Media & Performance
Media Type Supported: Twisted Pair
Ethernet Technology: 10 Gigabit Ethernet
Network Technology: 10GBase-T
Physical Characteristics
Height: 1.2″
Width: 14.4″
Depth: 16″
Miscellaneous
Package Contents:
- WS-X6716-10T-3C Switching Module
- 1 x Distributed Forwarding Card-3C (WS-F6700-DFC3C)
Compatibility:
Cisco Catalyst 6500 Series
Warranty
Limited Warranty: 90 Day
