Manufacturer: IBM Corporation
Manufacturer Part Number: 1746-C4A
Manufacturer Website Address: http://www.ibm.com
Brand Name: IBM
Product Line: System Storage
Product Series: DS3500 Express
Product Model: 1746C4A
Product Name: System Storage DS3524 Express
Marketing Information:
The IBM® System Storage® DS3500 Express Storage™ Systems and EXP3500 Express Expansion Units are the newest addition to the IBM System Storage DS3000 series family of entry disk storage systems. The DS3500 delivers affordable, entry-level configurations for small and medium businesses in compact 2U, 19-inch rack mount enclosures, with the flexibility to scale in capacity, performance, host interfaces, and advanced functions as your business grows or requirements change.
Product Type: DAS Storage System
Storage
Number of Hard Drives Supported: 24
Total Hard Drive Capacity Supported: 12 TB
I/O Expansions
Number of Total Expansion Bays: 24
Number of 2.5″ Bays: 24
Controllers
RAID Supported: Yes
RAID Levels:
- 0, 1, 3, 5, 6, 10
- 1
- 3
- 5
- 6
- 10
Interfaces/Ports
Host Interface: 6Gb/s SAS
Power Description
Number of Power Supplies Installed: 2
Maximum Power Supply Wattage: 585 W
Redundant Power Supply: Yes
Physical Characteristics
Height: 3.5″
Width: 19″
Depth: 19.6″
Form Factor: Rack-mountable
Rack Height: 2U
Weight (Approximate): 44.50 lb
Warranty
Limited Warranty: 3 Year
