Juniper SCBE2-MX-S Switch Fabric Module

The Switch Control Board (SCBE2) serves the carrier Ethernet services router and carrier Ethernet transport markets that require higher-capacity traffic support, demanding greater interface density (slot and capacity scale) as well as improved services. The upgraded SCB is supported on MX960, MX480, and MX240 routers. Some key attributes of the SCBE2 are:

• A bandwidth of up to 340 Gbps per slot with redundant fabric support and 480 Gbps per slot without redundancy, and improved fabric performance on account of using the next-generation fabric (XF2) chip.
• A central clocking module and a centralized clocking architecture that support clock cleanup and distribution. The Stratum 3 clock module performs clock monitoring, filtering, and holdover at a centralized chassis location.
• Full performance with fabric redundancy for higher-capacity line cards such as MPC4.
• Support for MPC line cards only.
• Two 10-Gigabit Ethernet SFP+ ports. SFP+ port 0 can be used to connect an external device as a Router Reflector. SFP+ port 1 is unused.
• Support for cross-coupling of clock input (which requires an enhanced midplane: CHAS-BP3-MX960-S). You can configure the system such that one SCBE2 supports a GPS interface, and the other SCBE2 supports a BITS interface.

Product Type: Switch Fabric Module
Technical Information
Application/Usage: Switching Fabric
Interfaces/Ports
Total Number of Ports: 1
Connector Type: RJ-45
Interfaces/Ports Details: 1 x RJ-45 1000Base-T Management
Media & Performance
Media Type Supported:

• Optical Fiber
• Twisted Pair

Ethernet Technology: 10 Gigabit Ethernet
Network Technology:

• 10GBase-X
• 1000Base-T

I/O Expansions
Number of Total Expansion Slots: 2
Expansion Slot Type: SFP+
Miscellaneous
Compatibility: Juniper Networks 3D Universal Edge Router:

• MX960
• MX480
• MX240
