Manufacturer: Juniper Networks, Inc
Manufacturer Part Number: SRX-GP-1DS3-E3
Manufacturer Website Address: http://www.juniper.net
Brand Name: Juniper
Product Model: SRX-GP-1DS3-E3
Product Name: SRX-GP-1DS3-E3 Gigabit-Backplane Physical Interface Module
Marketing Information:
The 1-Port Clear Channel DS3/E3 GPIM functions as a clear channel interface that can support DS3 (T3) or E3 line rates of 44.796 or 34.368 Mbps, respectively. The device does not support channelization, but it supports a subrate DS3/E3 configuration. The DS3/E3 interface is a popular high-bandwidthWAN interface for large enterprise branch locations that enables high-quality voice, video, and data applications with reduced latency. The clear channel implementation provides such features as subrate and scrambling options used bymajor DSU vendors. The interface also supports loopback, bit error rate test (BERT), and far-end alarmand control (FEAC) diagnostic capabilities. It supports Frame Relay, Point-to-Point Protocol (PPP), and High-Speed Data Link Control (HDLC) serial encapsulation protocols.
Product Type: WAN Interface Card (WIC)
Technical Information
Application/Usage:
- Data Networking
- Optical Network
- Wide Area Network
Interfaces/Ports
Total Number of Ports: 1
Connector Type: BNC
Interfaces/Ports Details: 1 x BNC DS-3/E-3 WAN
Physical Characteristics
Form Factor: Hot-swappable
Height: 0.8″
Width: 6.7″
Depth: 8.5″
Weight (Approximate): 1.11 lb
Miscellaneous
Compatibility:
Juniper Networks SRX Series Services Gateways
Environmentally Friendly: Yes
Environmental Certification: RoHS
Warranty
Limited Warranty: 1 Year
